28-Port 10 Gigabit Smart Managed Switch with 24 SFP+ ports and 4 10GBASE-T ports

DXS-1210-28S

  • 24x 10Gigabit SFP+ ports and Four 10GBASE-T ports
  • Up to 32K MAC address table size to connect more clients
  • Easy to configure with rich set of SMB features
  • Automatic Voice and Surveillance VLANs
  • Inter-VLAN and static routing support, IPv6 ready
  • Cable Diagnostics & Loopback Detection built-in

RRP NZ$4399.99

Business Solutions / Switching / Smart Switches / 28-Port 10 Gigabit Smart Managed Switch with 24 SFP+ ports and 4 10GBASE-T ports
10-Gigabit ports
10-Gigabit ports

10GbE connections for low-latency, to easily meet high-bandwidth demands, and device flexibility across the network.

Web-based GUI
Web-based GUI

Intuitive remote management interface makes setups and configurations easier, and reduces switch deployment times.

Layer 2 Features
Layer 2 Features

Includes port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP).

Layer 3 Lite Features
Layer 3 Lite Features

Such as IP Interfaces, ARP, IPv6 Neighbor Discovery (ND), Default Routing and Static Routing.

Energy Saving Technology
Energy Saving Technology

Powers down any unused ports, and includes LED shut-off, port shut-off, port standby.

Quality of Service
Quality of Service (QoS)

Rich QoS controls, including bandwidth control, and Auto Surveillance VLAN.

Network Security
Network Security

D-Link’s Safeguard Engine™ helps protect against traffic flooding from malicious attacks.

Limited Lifetime Warranty & Next Day Service
Limited Lifetime Warranty & Next Day Service

Register to enjoy D-Link Limited Lifetime Warranty support. We’ll also send out a replacement product to you on the next business day after acceptance of product failure.





Alleviate Network Congestion

Add 10‑Gigabit Ethernet connectivity with these affordable high-performance switches. Designed for deployment in small to medium-sized business (SMB) core networks and powerful enough for enterprise aggregation applications.

Extensive Layer 2 & Layer 3 Lite features.

The DXS-1210 series includes layer 2 features such as port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). They also support IP interfaces, ARP, IPv6 Neighbor Discovery (ND), default routing, IPv4/IPv6 static routing, IGMP and MLD Snooping, auto voice and surveillance VLAN, LLDP and LLDP-MED.

Improved intranet performance
Inter-VLAN routing allows traffic to be routed between VLANs without passing through the router, reducing the load on the router as well as the backbone networks.

Security and QoS controls for priorities
Security controls for protection of the network, and QoS ensures essential traffic reaches its destination.

Seamless integration.

The DXS-1210 Series comes with both RJ45 and SFP+ ports capable of connecting to Cat. 6 and fibre for 10G Ethernet. Additionally, the DXS-1210-28S comes with 4 x 10/25G SFP28 ports. This means the DXS-1210 series can provide a flexible solution for upstream or downstream server connections, making network deployment easier.

Security with every port.

The innovative D-Link Safeguard Engine protects the switches against traffic flooding caused by malicious attacks and increases overall network reliability.

These switches also feature Address Resolution Protocol (ARP) spoofing prevention which further protects the network from cyber attacks. They also use packet control ACLs to block invalid packets that contain fake ARP messages.

The Access Control List (ACL) helps protect the internal IT network through permission-based network access.

The DHCP server screen feature filters DHCP replies on unauthorised ports to prevent them from being assigned an IP address.

And support for 802.1X port-based and host-based authentication allows the network to be authenticated through external RADIUS servers.

QoS and Bandwidth Control for network priorities.

The DXS-1210 Series supports Auto Surveillance VLAN (ASV) and Auto Voice VLAN, to make faster VoIP and video surveillance deployments.

Auto Surveillance VLAN
Automatically detects and assigns video surveillance traffic to a high-priority VLAN by creating distinct broadcast domains to guarantee that quality real-time video is transferred.

Auto Voice VLAN
Enhances the VoIP service by automatically placing voice traffic from IP phones to a designated VLAN. With a prioritised and segmented VLAN, this feature guarantees quality and security of VoIP traffic.

As a result, the voice and video packets take precedence over other packets. And with bandwidth control, more bandwidth can be reserved for important functions.


Switch Type :Layer2+ IP Routing
Type of Port Required :10 Gigabit Fibre
Number of Ports :24 - 28
PoE Type Required :None
High Speed Stacking :No
Design :Desktop|Rackmountable
Switching Capacity :560 Gbps
QoS :Yes
Spanning Tree Protocol :Yes
Link Aggregation :Yes
VLAN :4K Groups
Surveillance VLAN :Yes
Jumbo Frame :12K bytes
Voice VLAN :Yes
IGMP Snooping :Yes
802.1X Access Control :Yes
DHCP Server Screening :Yes
SNMP :Yes
Cable Diagnostics :Yes
Energy Saving Technology :EEE Compliant|D-Link Green
19" Rack Mountable :Yes
Fans :2
Built-in PSU :Yes
Dimensions (Size) : 441 x 210 x 44 mm
Web-based GUI :Yes
Command Line Interface :Yes
Types of ports :10Gb SFP+ Ports
10Gb SFP+ ports :24 ports
Static Routing :Yes
10GBase-T ports :4 ports
Switch Series :DGS-1210 Series
